The NXE-400V200kWh system is engineered to lower peak energy demand by utilizing stored power during periods of high consumption. With a 200kWh capacity, it ensures consistent energy delivery and helps businesses cut down on electricity expenses.
NXE-400V200kWh- High Voltage Commercial & industrial Battery Storage.
Product Features
Long life cycle
BESS controller offers millisecond-level response time and supports a wide range of energy storage system control functions
Compatible communication interface with BMS
Safest technology
High energy density
Compact & lightweight
Low self-discharge rate
Product Specifications
| Specification | Detail |
|---|---|
| Part Number | NXE-400V200kWh |
| Total Capacity | 504Ah |
| Nominal Voltage | 400Vdc |
| Maximum Charge Voltage | 448Vdc |
| Discharge Cut-off Voltage | 324Vdc |
| Peak Resistance | <100 mΩ |
| Continuous Charge Current | 600A |
| Continuous Discharge Charge Current | 600A |
| Self-discharge Rate | 2% Per Month |
| DOD | 100% |
| Casing Material | Steel |
| Monitoring Data | SOC, voltage, current, temperature |
| Weight | 2000KG |
| Communication | CAN/485 |
| Terminals | High Power Energy Storage Terminals |
| Usage | Industry |
